Peerless-AV SmartMount PT640 Universal Tilt Wall Mount for 32″ to 46″ Displays
The Paramount™ series wall mounts provide versatile and multi-functional features. With PT64, a low-profile design positions the display just 2.63″ (67mm) from the wall. The Hook-and-Hang™ system offers easy, one-person installation of the display. The Easy-Glide™ adaptors hook onto the wall plate for a quick, simple, and secure installation. Achieve perfect positioning of the display with the side-to-side adjustment after installation. A ratcheting handle provides locking tilt capability for quick adjustments to the amount of tilt, reducing glare and optimizing the viewing angle. Lock the tilt angle at installation to prevent tampering or moving with the IncreLok™ tilt technology.
This display size range is simply a guideline for product selection. Displays larger than the screen size range may still be compatible as long as they fall within the VESA® pattern and max weight of the Peerless-AV® product.
Product Features
- Universal mount fits displays with mounting patterns up to 450 x 305mm (17.72″ W x 12.01″ H) and accommodates up to 400 x 300mm VESA® mounting patterns
- Adjustable 15° forward tilt and 5° backward tilt for finding the optimal viewing angle
- Easy-Grip ratcheting handle locks tilt angle into place
- Included IncreLok™ feature offers fixed tilt lock in 5° increments when used
- Horizontal display adjustment up to 6.00″ (152mm) for centering display on wall
- Landscape to portrait mounting options increases installation versatility. Please check display dimensions against the wall plate when used in portrait mode*
- Design is UL listed and tested to four times stated load capacity
- Includes all necessary wall and display attachment hardware
- * Requires display to be removed and reset on mount
Technical Specifications
| Product Information | |
| Device Supported |
OLED TV Display |
| Maximum Load Capacity | 45.36 kg |
| Minimum Screen Size Supported | 32″ (81.28 cm) |
| Maximum Screen Size Supported | 46″ (116.84 cm) |
| Minimum Adjustable Depth | 6.68 cm (2.63″) |
| Maximum Adjustable Depth | 12.04 cm (4.74″) |
| Features | Tilt |
| Locking Mechanism | |
| Adjustable | |
| Hook And Hang Design | |
| Ratcheting Handle | |
| Lockable | |
| Reduced Glare | |
| Increlock | |
| Horizontal Adjustment | |
| Orientation | Landscape / Portrait |
| Mount Pattern | Universal |
| Mount Profile | Low Profile |
| Minimum Tilt Angle | -5° |
| Maximum Tilt Angle | 15° |
| Mount Function | Adjustable |
| Wall Mount | |
| Tilt | |
| Lockable | |
| Mount Surface | Wall |
| Durability | Scratch Resistant |
| Tamper Resistant | |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Finishing | High Gloss |
| Fused Epoxy | |
| VESA Mount Compatible | Yes |
| Mounting Pattern | 200 x 100 |
| 200 x 200 | |
| 300 x 200 | |
| 300 x 300 | |
| 400 x 200 | |
| 400 x 300 | |
| Form Factor | Wall Mountable |
| Height | 32.54 cm (12.81″) |
| Width | 55.45 cm (21.83″) |
| Depth | 12.04 cm (4.74″) |
| Weight (Approximate) | 2.95 kg |
| Miscellaneous | |
| Package Contents | Universal Tilt Wall Mount for 32″ to 46″ Displays |
| Wall and Display Installation Hardware | |
| Installation Instructions | |
| Indoor/Outdoor | Indoor |
| Certifications & Standards | RoHS, TAA, VESA, UL, OSHPD |
| Manufacturer Product Class | Tilt |
| Assembly Required | Yes |
| TAA Compliant | Yes |
| UL Listed | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 5 Year |
