Samsung 55” Odyssey Ark 2nd Gen, UHD, Smart Gaming Monitor
- Overwhelm your senses with 55″ large screen & 1000R curvature
- Swing into groundbreaking views with Cockpit Mode & Eclipse Lighting
- Ark Dial puts the player in full control of Ark, allowing quick and simple access to a variety of functions
Technical Specifications
| Display | |
| Screen Size (Class) | 55 |
| Flat / Curved | Curved |
| Active Display Size (HxV) (mm) | 1209.6(H) x 680.4(V) |
| Screen Curvature | 1000R |
| Aspect Ratio | 16:9 |
| Panel Type | VA |
| Brightness (Typical) | 600 cd/㎡ |
| Brightness (Min) | 420 cd/㎡ |
| Contrast Ratio Static | 1,000,000:1 (Static) |
| Contrast Ratio (Dynamic) | Mega DCR |
| HDR(High Dynamic Range) | Quantum HDR 32x |
| HDR10+ | HDR10+ Gaming |
| Mini LED Local Dimming | Yes (1,056 zones) |
| Resolution | 4K (3,840 x 2,160) |
| Response Time | 1ms(GTG) |
| Viewing Angle (Horizontal/Vertical) | 178°(H)/178°(V) |
| Colour Support | Max 1B |
| Colour Gamut (NTSC 1976) | N/A |
| Color Gamut (DCI Coverage) | 95%(Typ.) |
| sRGB Coverage | N/A |
| Adobe RGB Coverage | N/A |
| Refresh Rate | Max 165Hz |
| General Feature | |
| Eco Saving Plus | N/A |
| 0.00 W Off mode | N/A |
| Eye Saver Mode | Yes |
| Flicker Free | Yes |
| Picture-In-Picture | N/A |
| Picture-By-Picture | N/A |
| Quantum Dot Color | Yes |
| Game Mode | Yes |
| Image Size | Yes |
| Daisy Chain | N/A |
| Windows Certification | Windows 10 |
| FreeSync | FreeSync Premium Pro |
| G-Sync | N/A |
| VESA Adaptive-Sync | N/A |
| Off Timer Plus | Yes |
| Black Equalizer | N/A |
| Low Input Lag Mode | N/A |
| Virtual AIM Point | Yes |
| Core Sync | N/A |
| Game Bar 2.0 | Yes |
| Gaming Hub | Yes (KR, US, CA, BR, GB, FR, DE, IT, ES) |
| Refresh Rate Optimizor | N/A |
| Super Arena Gaming UX | N/A |
| HDMI-CEC | Yes |
| Auto Source Switch | Auto Source Switch+ |
| Adaptive Picture | Yes |
| Ultrawide Game View | Yes |
| KVM Switch | Yes |
| Smart Service | |
| Smart Type | Smart |
| Operating System | Tizen™ |
| Bixby | US English, UK English, India English, Korean, French, German, Italian, Spanish, BR Portuquese (features vary by language) |
| Far-Field Voice Interaction | N/A |
| TV Plus | Yes (GB, FR, DE, IT, ES, CH, AT, NL, SE, NO, DK, FI, PT, IE, BE, LU) |
| Universal Guide | Yes (GB, FR, DE, IT, ES) |
| Alexa Built-in | Alexa (GB, DE, FR, IT, ES, AT, IE) |
| Video Communication | N/A |
| Web Service | Microsoft 365 |
| SmartThings Hub | Yes |
| Multi Device Experience | Mobile to Screen, Screen initiate mirroring, Screen Sound to Mobile, Sound Mirroring, Wireless On |
| Wireless DeX | Yes |
| My Contents | Yes |
| ScveenVitals | N/A |
| Multi View | Yes |
| Smart Calibration | Basic |
| NFT | Nifty Gateway |
| Knox Vault | N/A |
| Tap View | Yes |
| Remote Access | Yes |
| Interface | |
| Wireless Display | Yes |
| Dual Link DVI | N/A |
| Display Port | 1 EA |
| Display Port Version | 1.4 |
| HDCP Version (DP) | 2.2 |
| HDMI | 3 EA |
| HDMI Version | 2.1*2, 2.0*1 |
| HDCP Version (HDMI) | 2.2 |
| Headphone | Yes |
| USB Hub | 2 |
| USB Hub Version | 2 |
| Ethernet (LAN) | 1 EA |
| Wireless LAN Built-in | Yes (WiFi5) |
| Bluetooth | Yes (5.2) |
| Built-in Camera | No |
| Windows Hello Certification | N/A |
| Audio | |
| Speaker | Yes |
| Speaker Output | 60W |
| Adaptive Sound | Yes |
| Operation Conditions | |
| Temperature | 0℃~40℃ |
| Humidity | 10%~80%, Non-Condensing |
| Calibration | |
| Factory Tunning | Yes |
| Colour Mode | Eco/Standard/Dynamic/Movie/Graphic/Entertain/Filmmaker Mode |
| CMS(Colour Management Software) | N/A |
| Factory Calibration Report | Yes |
| Design | |
| Front Colour | TITAN BLACK |
| Rear Color | BLACK |
| Stand Color | BLACK |
| Stand Type | HAS PIVOT |
| HAS(Height Adjustable Stand) | Landscape : 0~270mm(±5mm), Portrait : 0~30mm(±5mm) |
| Tilt | Landscape : -10˚(±2˚)~10˚(±2˚), Portrait : -13˚(±2˚)~10˚(±2˚) |
| Swivel | N/A |
| Pivot | -90˚(±2˚)~90˚(±2˚) |
| Wall Mount | 200 x 200 |
| Eco | |
| Energy Efficiency Class | G |
| Recycled Plastic | N/A |
| Power | |
| Power Supply | AC100-240V 50/60Hz |
| Power Consumption (Max) | 140 W |
| Power Consumption (Typ) | 80.0 W |
| Power Consumption (DPMS) | 0.50 W |
| Power Consumption (Off Mode) | N/A |
| Power Consumption (Yearly) | 117 kWh/year |
| Type | Internal Power |
| Dimension | |
| Set Dimension with Stand (WxHxD) | 1174.8 x 1102.0 x 379.0 mm |
| Set Dimension without Stand (WxHxD) | 1174.8 x 704.8 x 251.8 mm |
| Package Dimension (WxHxD) | 1362.0 x 922.0 x 317.0 mm |
| Weight | |
| Set Weight with Stand | 41.5 kg |
| Set Weight without Stand | 21.1 kg |
| Package Weight | 57.1 kg |
| Accessory | |
| Power Cable Length | 1.5 m |
| HDMI Cable | Yes |
| Remote Controller | Yes |
| Certification and Compliance | |
| UL Glare Free | Yes |
