Samsung 85″ QET Crystal UHD 4K Signage Display
Samsung’s QET series features intelligent upscaling technology that displays all content in eye-catching UHD resolution along with a sleek design and simple content management features.
- Upscale your business
- Incredible UHD picture quality
- Crisp and vivid color expression
Technical Specification
| Display | |
| Diagonal Size | 85″ |
| Panel Type | VA |
| Resolution | 3,840 x 2,160 |
| Pixel Pitch (HxV) | 0.4875 (H) x 0.4875(W) mm |
| Brightness (Typ) | 300 nit |
| Contrast Ratio | 4,000:1 |
| Viewing Angle (Horizontal/Vertical) | 178/178 |
| Response Time | 8ms |
| Colour Gamut | 72% |
| Glass Haze | 2% |
| H-Scanning Frequency | 15 ~ 135kHz |
| Maximum Pixel Frequency | 594MHz |
| V-Scanning Frequency | 24 ~ 75Hz |
| Contrast Ratio (Dynamic) | Mega |
| Operation Time Support | 16/7 |
| Connectivity | |
| HDMI In | 2 |
| Version of HDMI | 2.0 |
| Version of DP | No |
| Version of HDCP | 2.2 |
| USB | 1 |
| Audio Out | Stereo Mini Jack |
| RS232 In | Stereo Mini Jack |
| RJ45 In | Yes |
| 3G Dongle | No |
| Power | |
| Power Supply | AC100-240V 50/60Hz |
| Power Consumption (On Mode) | 275 W |
| Power Consumption (Sleep Mode) | 0.5 W |
| Dimension | |
| Set Dimension (WxHxD) | 1900.9 x 1086.2 x 26.9 mm |
| Package Dimension (WxHxD) | 2075 x 1237 x 220 mm |
| Weight | |
| Set Weight | 41.5 kg |
| Package Weight | 54.3 kg |
| Operation Conditions | |
| Temperature | 0℃~ 40℃ |
| Humidity | 10 ~ 80%, non-condensing |
| Mechanical Specification | |
| VESA Mount | 600 x 400 mm |
| Bezel Width | 3 Bezel-less |
| Frame Material | Glossy |
| Optional Feature | |
| Mount | WMN8200SG |
| SoC | |
| OS Version | Tizen 4.0 |
| Flash Memory Size | 8GB |
| Certification and Compliance | |
| EMC | Class B |
| Safety | 60950-1, 62368-1 |
