Samsung 46″ OHB-S Outdoor Signage Display – LH46OHBESGBXEN
- UL-verified for outdoor visibility with greater brightness than 3,500nit and 24/7 performance.
- Advanced color accuracy and brightness, creating vivid content.
- Enhanced visibility with anti-reflection technology by Magic Protection Glass.
- Prevent humidity for optimal performance with hidden fans in the downside of the display.
Product Specifications
| Display | |
| Diagonal Size | 46″ |
| Panel Type | VA |
| Resolution | 1,920 x 1,080 |
| Pixel Pitch (HxV) | 0.53×0.53mm |
| Brightness (Typ) | 3,500 (Peak 4,000 ) |
| Contrast Ratio | 6,000:1 |
| Viewing Angle (Horizontal/Vertical) | 178/178 |
| Response Time | 6ms |
| Colour Gamut | NTSC 72% |
| Glass Haze | 0% |
| H-Scanning Frequency | 15~135kHz(HDMI) |
| Maximum Pixel Frequency | 594MHz(HDMI) |
| V-Scanning Frequency | 24~75Hz(HDMI) |
| Contrast Ratio (Dynamic) | Mega |
| Operation Time Support | 24/7 |
| Connectivity | |
| HDMI In | 2 |
| Version of HDMI | 2 |
| Version of HDCP | 2.2 |
| USB | 1 |
| HDBaseT In | Yes |
| Audio Out | Stereo Mini Jack |
| Video Out | No |
| RS232 In | Yes |
| RS232 Out | Yes |
| RJ45 In | Yes |
| RJ45 Out | Yes |
| Power | |
| Power Supply | AC100-240V 50/60Hz |
| Power Consumption (On Mode) | 430W |
| Power Consumption (Sleep Mode) | 0.5W |
| Dimension | |
| Set Dimension (WxHxD) | 1069 x 623.6 x 85 mm |
| Package Dimension (WxHxD) | 1156 x 713 x 200 mm |
| Weight | |
| Set Weight | 36 kg |
| Package Weight | 40.5 kg |
| Operation Conditions | |
| Temperature | -30℃~ 50℃ |
| Humidity | 10 ~ 80%, non-condensing |
| Mechanical Specification | |
| VESA Mount | 995 x 500 mm |
| Bezel Width | 24.9mm (T/B/L/R) |
| Glass Thickness | 5T |
| Glass Film | AG, AR, 4/λ |
| SoC | |
| OS Version | Tizen 6.5 |
| Flash Memory Size | 8GB |
| Certification and Compliance | |
| EMC | Class A |
| Safety | 60950-1, 62368-1 |
