Samsung 55″ Flip Pro WM55B UHD 4K Interactive Display
As digitalisation of education accelerates to enable impactful, interactive collaboration, Flip Pro gives educators the tools needed to deliver a new, advanced level of learning. With versatile connectivity, intelligent software and intuitive features, Flip Pro introduces the future of education.
- Multi Writing
- Versatile connectivity
- Powerful touch function
Note:- These units have some stylus marks from previous use which can be seen when the unit is powered off. This is standard for these displays and in no way affects the picture or performance when in use.
Technical Specifications
| Display | |
| Diagonal Size | 55″ |
| Panel Type | VA |
| Resolution | 3,840 x 2,160 |
| Pixel Pitch (HxV) | 0.315 x 0.315 |
| Brightness (Typ) | 350cd/m2 (w/o glass), 220cd/m2 (w/glass) |
| Contrast Ratio | 4000:1(without glass) |
| Viewing Angle (Horizontal/Vertical) | 178/178 |
| Response Time | 8ms |
| Colour Gamut | 72% |
| Glass Haze | 2%(without glass) |
| H-Scanning Frequency | 30~81 khz |
| Maximum Pixel Frequency | 594Mhz |
| V-Scanning Frequency | 48~75 Khz |
| Operation Time Support | 16/7 |
| Connectivity | |
| HDMI In | 2 |
| DP In | 1 |
| Version of HDMI | 2 |
| Version of DP | 1.2 |
| Version of HDCP | 2.2 |
| USB | 1(Rear), 3 (with optional front tray, Internal 1, External 1, USB-C 1) |
| Audio Out | Stereo Mini Jack |
| RS232 In | Yes |
| RJ45 In | Yes |
| WiFi | Yes |
| Bluetooth | Yes |
| Power | |
| Power Supply | AC100-240V 50/60Hz |
| Power Consumption (On Mode) | 154W |
| Power Consumption (Sleep Mode) | 0.5W |
| Dimension | |
| Set Dimension (WxHxD) | 1297.4 x 768.2 x 59.9 mm |
| Package Dimension (WxHxD) | 1464 x 915 x 190 mm |
| Weight | |
| Set Weight | 28.6 kg |
| Package Weight | 35.9 kg |
| Operation Conditions | |
| Temperature | 0℃~40℃ |
| Humidity | 10 ~ 80%, non-condensing |
| Mechanical Specification | |
| VESA Mount | 400 x 400 mm |
| Bezel Width | 26.2 |
| Frame Material | Plastic |
| Optional Feature | |
| Touch | Yes |
| Mount | Yes(Model Name : WMN-4277SF) |
| Stand | Yes(Model Name : STN-WM55R) |
| SoC | |
| OS Version | Tizen 6.5 |
| Flash Memory Size | 32GB |
| Touch | |
| Touch Technology | IR |
| Certification and Compliance | |
| EMC | Class A FCC (USA) Part 15, Subpart B KCC/EK (Korea) Tuner : KN32 / KN35 Tunerless : KN32 / KN35 CE (Europe) EN55032 : 2012 or 2015 EN55024:2010 or EN 55035:2017 VCCI (Japan) VCCI CISPR32:2016 CCC(China) GB/T9254-2008 GB17625.1-2012 BSMI (Taiwan) CNS13438 ( ITE EMI ) CNS14336-1 ( ITE Safety ) CNS15663 (RoHS) C-Tick (Australia) AS/NZS CISPR32:2015 GOST(Russia/CIS) ROCT CISPR 24-2013 ROCT CISPR 22:2005 |
| Safety | CB (Europe) : IEC60950-1/EN60950-1CCC (China) : GB4943.1-2011PSB (Singapore ) : PSB+IEC60950-1NOM (Mexico ) : NOM-001-SCFI-1993IRAM (Argentina ) : IRAM+IEC60950-1SASO (Saudi Arabia ) : SASO+IEC60950-1BIS(India) : IEC60950-1 / IS13252NOM(Mexico) : Tuner : NOM-001-SCFI-1993 Tunerless : NOM-019-SCFI-1998KC(Korea) : K 60950-1EAC(Russia) : EAC+IEC60950-1INMETRO(Brazil) : INMETRO+IEC60950-1BSMI(Taiwan) : BSMI+IEC60950-1RCM(Australia) : IEC60950-1/AS/NZS 60950-1UL(USA) : cUL60950 |
