Samsung QBC Series 24″ Small Signage Display
Get the most out of every space with Samsung QB24C small digital signage. The compact display provides sharp messaging with its Full HD resolution. Its enhanced internal solutions and intuitive home screen UX make it easy to use, also ensuring reliable performance for any business use.
- Enhanced picture quality
- Sleek stylish design capturing audience’s attention
Technical Specifications
Display | |
Diagonal Size | 23.8″ |
Panel Type | ADS |
Resolution | 1,920 x 1,080 |
Pixel Pitch (HxV) | 0.2745 x 0.2745 mm |
Brightness (Typ) | 250 nit |
Contrast Ratio | 1,000:1 |
Viewing Angle (Horizontal/Vertical) | 178/178 |
Response Time | 14ms |
Colour Gamut | 72(NTSC) |
Glass Haze | 25 % |
H-Scanning Frequency | 56~84.5KHz |
Maximum Pixel Frequency | 148.5MHz |
V-Scanning Frequency | 48~75Hz |
Contrast Ratio (Dynamic) | Mega |
Operation Time Support | 16/7 |
Connectivity | |
HDMI In | 1 |
DP In | No |
Version of HDMI | 1.4 |
Version of DP | No |
Version of HDCP | 2.2 |
USB | 1 |
IR In | Yes |
Audio In | No |
Audio Out | Stereo Mini Jack |
RS232 In | Yes |
RJ45 In | Yes |
WiFi | Yes |
Bluetooth | Yes |
Power | |
Power Supply | AC100-240V 50/60Hz |
Power Consumption (On Mode) | 38.5 W |
Power Consumption (Sleep Mode) | 0.5 W |
Dimension | |
Set Dimension (WxHxD) | 547.9 x 334.4 x 31.8 mm |
Package Dimension (WxHxD) | 620 x 419 x 122 mm |
Weight | |
Set Weight | 3.0 kg |
Package Weight | 4.1 kg |
Operation Conditions | |
Temperature | 0 °C~ 40 °C |
Humidity | 10 ~ 80%, non-condensing |
Mechanical Specification | |
VESA Mount | 100 x 100 mm |
Bezel Width | UD : 17.9 / LR : 9.4 |
Frame Material | Non-Glossy |
SoC | |
OS Version | Tizen 7.0 |
Flash Memory Size | 8GB |
Certification and Compliance | |
EMC | Class B |
Safety | 60950-1, 62368-1 |
